3M Scotch-Weld AF 555M Structural Adhesive Film 0.05Wt 36in x 50Yd Roll (Freezer Storage -18°C)

Name: 3M Scotch-Weld AF 555M Structural Adhesive Film 0.05Wt 36in x 50Yd Roll (Freezer Storage -18°C)
SKU: P0190381
Price: 7303.290000 GBP

Silmid P/N: P0190381

Remove From Favourites Add To Favourites

£7303.29 (excl VAT) £8763.95 (Inc VAT)

3M Scotch-Weld Structural Adhesive Film AF 555M encompasses a family of thermosetting modified epoxy adhesives in film form that provides long-term durability and meets specific challenges for metal and composite solid panel.

Technical Information

Commodity Code 56031290
Country of Origin United States

3M FREEZER: This product should be stored in the freezer and it is recommended that orders are shipped with DRY ICE. Please click here to add this to your basket.

AUTHORISED DISTRIBUTOR: Silmid is an authorised distributor of 3M Aerospace products. Click here to review our authorised distributor certificate.

Data Sheets

Download the 3M AF 555M technical data sheet (TDS) and the 3M AF 555M safety data sheet (SDS) from Silmid today. Once you have logged in or signed up, the datasheet will be visible for download if one is available.

Product Properties

Pack Size

0.05Wt 36in x 50Yd Roll

Product Colour

Orange

Brand

3M Scotch-Weld

Manufacturer Name

3M PLC

Manufacturer Part Number

7000058925

Cure Temperature

175°C

EAN

10048011532209

Specifications

Boeing

BMS 5-160 Type I Grade 5

Please Note: Specifications and approvals are subject to change at any time. Users should always consult their AMM or the OEM when selecting products to ensure items have the release needed. Only specifications listed on the order confirmation will be certified on the Silmid CofC.

Product Information

3M Scotch-Weld Structural Adhesive Film AF 555M provides excellent performance with easy-to-use shop handling properties. These adhesive films are available in a variety of weights and carriers to meet a range of needs without imposing excess material costs.

With high fracture toughness and peel strength, AF 555M provides a reliable, long-term bond suitable for composites, metals in solid panel and honeycomb sandwich fabrication. We also offer an unsupported version, which can be used for reticulation. It is also compatible with multiple substrates and primers. In addition, AF 555M exhibits excellent pre-bond humidity performance on composite substrates.

Features:

Structural adhesive film with long-term durability on honeycomb.
Offers pre-bond humidity performance on composite substrates
One year out time at ambient conditions
Excellent shop handling characteristics
0.05 x 36 in x 50 Yd Roll
200ml

This heat-curing, easy handling film is designed to meet numerous customer specs in aerospace manufacturing. AF 555M supplies high fracture toughness through a spectrum of environmental conditions and is easy to work with. Once cured it provides high bond strength from -67°F to 325°F (-55°C to 163°C) for use in multiple designs through multiple environments.
