Elmotherm® 073-1010 is a solvent, specially modified isophthalic varnish, which has an excellent long-term tank stability. The cured product gives a tough / resilient film with excellent chemical and moisture resistance.
Elmotherm® 073-1010 has a thermal class of 180°C (class `H`) and exhibits compatibility with most types of insulation products and systems (UL class systems are available containing this product) and is ideally suited for processing of transformers, especially where a clean drain characteristic and fast cure is required as well as the impregnation of small stators and coils where flexibility of connection leads has to be maintained. It is designed for use in applications where high bond strength and good moisture and chemical resistance is required.
Polymerization is initiated by the effect of heat and proceeds as a rapid chain-reaction until a threedimensionally cross linked, duroplastic cured material is produced. The product fulfils the directive 2011/65/UE e2002/95/CE (RoHS). The raw materials of the product are pre-registered according to directive to CE 1907/2006 and s.m.i. (REACH). The product does not contain polycyclic aromatic hydrocarbons and substances listed in the SVHC Candidate List.
- Elmotherm Varnish
Specifications and Information
Document DownloadsSil-Mid Limited DO NOT GUARANTEE that the information in these documents is the most up to date information available from the manufacturer, there are times when updated information is released and we are not made aware immediately.
