XIAMETER™ RBL-9694-45M Silicone Elastomer 36.2Kg Kit

XIAMETER™ RBL-9694-45M Silicone Elastomer 36.2Kg Kit
Xiameter RBL-9694-45M Two-part silicone elastomer for integrated compression seals. read more
£1956.34 excl VAT
(£2347.61 Inc VAT)
No stock - lead time 31 days
Please order in multiples of 5
Bulk discounts
£1956.34 + VAT
£1858.52 + VAT
£1809.61 + VAT
£1760.71 + VAT

Product Information

DescriptionXIAMETER RBL-9694-45M Kit is a two component heat-cure silicone elastomer, designed to be easily mixed and dispensed via meter-mix equipment. It is cured directly on automotive and other industrial components to form an integrated, high strength compression seal. It is resistant to many industrial fluids (e.g. engine oils, water/glycol mixtures) over a broad temperature range with the exception of fuels and nonpolar solvents.


  • Two-part addition cure silicone elastomer
  • User-friendly, easy to handle
  • 1:1 mix ratio
  • High tear resistance
  • Low compression set
  • Good adhesion to many substrates
  • Long term stability over a wide temperature range (-50ºC to +200ºC)


  • Hardness suitable for sealing applications under high clamping loads
  • Non-sag nature yields accurate, uniform gasket beads of precise dimensions as defined by robot application parameters
  • Fast cure at elevated temperatures, no post curing
  • Does not require solvents, CFCs or other environmentally harmful materials for processing

ApplicationsXIAMETER® RBL-9694-45M Kit is designed to be dispensed and cured directly on automotive and other industrial components to form integrated gaskets. Typical applications include gaskets for components which require high clamping forces, e.g. cam covers, water pumps, ABS modules and thermostat housings.

Specifications and Information

Technical Information

£1956.34 excl VAT
(£2347.61 Inc VAT)
No stock - lead time 31 days
Product Code
Commodity Code
Country Of Origin
United States

Document Downloads

Sil-Mid Limited DO NOT GUARANTEE that the information in these documents is the most up to date information available from the manufacturer, there are times when updated information is released and we are not made aware immediately.
